Brand : Berjaya
Product Sku : 1646
| Model | 1 Deck BJY-E3KW-1BD |
1 Deck BJY-E6KW-1BD |
2 Decks BJY-E13KW-2BD |
3 Decks BJY-E20KW-3BD |
3 Decks BJY-E25KW-3BD |
|---|---|---|---|---|---|
| Capacity (Kg/hr) | 10 | 20 | 40 | 60 | 90 |
| Temperature Range (°C) | 20 - 300 | 20 - 300 | 20 - 300 | 20 - 300 | 20 - 300 |
| Voltage / Phase (V/Ph) | 220 - 240 / 1 | 220 - 240 / 1 | 380 - 415 / 3 | 380 ~ 415 / 3 | 380 ~ 415 / 3 |
| Frequency (Hz) | 50 / 60 | 50 / 60 | 50 / 60 | 50 / 60 | 50 / 60 |
| Rated Input Power (W) | 3000 | 6600 | 13200 | 19800 | 25200 |
| Inner Dimension / Deck (mm) | 650 x 530 x 180 | 870 x 670 x 200 | 870 x 670 x 200 | 870 x 670 x 200 | 1290 x 670 x 200 |
| Machine Dimension (mm) | 920 x 700 x 410 | 1250 x 845 x 615 | 1250 x 845 x 1220 | 1250 x 845 x 1615 | 1670 x 845x 1640 |
| Packing Dimension (mm) | 980 x 740 x 450 | 1310 x 905x 655 | 1310 x 905 x 1260 | 1310 x 905 x 1655 | 1730 x 905 x 1680 |
| No. of Baking Tray | 1 | 2 | 4 | 6 | 9 |
| Weight (Kg) | 41 | 85 | 150 | 200 | 280 |
| Remarks | - | * Isolator 35A / 1 Phase required |
- | - | - |
